Ram TR 1360

THIS PRODUCT IS PART OF THE GREENSPIRIT RANGE, OUR COMPLETE EXTRICATION SOLUTION. Rescue hydraulic ram with battery for more mobile and flexible use. DELIVERING HIGH STROKE AT 1,386 MM

Scorpe - Ram TR 1360
RAM TR 1360
1 / 2
  • Scorpe - Ram TR 1360
  • RAM TR 1360
Description
The TR ram is used to create and stabilize openings after a car or truck accident in order to free victims.
It can also be used to maintain a structure after a collapsed building or a natural disaster. Telescopic Ram with total length of 1386 mmm.
Its special head design with 4 pointed tips will maintain a strong and safe grip on any structure and its 360° head rotation will enable to manoeuver the ram easily in many angles.
It is also pretty easy to store thanks to its compactness !Size L x l x H : 586x134x349 mm.
Characteristics
DIMENSIONS: L.586 x W.134 x H.349 mm
EXTENDED PISTONS LENGTH: 1386 mm
STROKE PISTON 1: 428 mm
STROKE PISTON 2: 372 mm
THRUST FORCE PISTON 1 & 2: 6.3Tto11T
WEIGHT (BATTERY INCLUDED): 20.1 kg
NOMINAL PRESSURE: 700 bar
CLASSE EN 13204: TR108/428-62/372-201-E-I
4 POINTED TIPS FOR A STRONG AND SAFE GRIP
360° ROTATING HEAD
EASE OF USE OF THE CONTROL HANDLE
Advantages
– INTUITIVE MARKING SYSTEM indicating remaining piston

ROBUSTNESS AND SAFET
– Reinforced composite shell with protective pads in case of impact
– Special design of the casing for a complete protection of the battery
– 4 LEDs to illuminate the cutting area
– Control unit away from the On/Off button for optimal safety
– Removable head on the fixed side of the cylinder. The two cylinder are treated for prolonged strength

ERGONOMIC AND AUTONOMOUS
– Compact and light weight while guaranteeing a long stroke thanksto the use of extensions (250 – 300 – 500 mm)
– Milwaukee M28 battery is non-captive and compatible with the entireM28 range Milwaukee, with long runtime of 45 min, Li-ion 5.0 Ah 28 V
– NON CAPTIVE battery available at all Milwaukee dealers

EASE OF USE
– Intuitive On/Off button with built-in light
– Central anti-slip handle for easy grip
– Easy and fast battery insertion and replacement
Accessories
Call us for more informations
